Vehicle Information
VIN:
JALE5B16177300698
Stock #:
596321
Model Code:
NR154
-
Condition Used
-
Body Style 2D Standard Cab -
Exterior Color White
-
Mileage 246,778
-
Engine 4 Cyl - 5.190 L -
Transmission 4-Speed Automatic with Overdrive -
Fuel Type Diesel
Highlighted Features
Feature availability subject to final vehicle configuration. Please reference window sticker for more info.
- Turbo Charged Engine
- Cruise Control
Dealer Comments
2007 Isuzu NQR White RWD I4
Eligible Benefits
All Features
- Truck Application
- GVWR, 17,950 lbs (8142 kg) capacity
- Air Cleaner, 12.6 in. diameter dry paper single element - Donaldson Brand, includes resonator
- Exhaust Brake, Butterfly valve type
- Alternator, 110 amp with integral regulator
- Battery, Dual Delco 12-V maintenance free 750 CCA each
- Exhaust System, Single horizontal aluminized steel
- Rear wheel drive
- Front GAWR, 6830 lbs (3098 kg) capacity
- Front Axle, Reverse Elliot "I"-beam rated at 6830 lbs. (3098 kg) - Includes integral hydraulic power steering, Ratio 18.8-20.9:1
- Front Suspension, Steel Alloy Tapered Leaf, 8440 lbs. (3828 kg) capacity - Semi-elliptical tapered leaf springs. Includes shock absorbers and stabilizer bar.
- Front Wheels, 19.5 x 6.0, 6-hole disc, painted white
- Front Tires, 225/70R19.5F (12 ply) tubeless Radial, all season tread.
- Rear GAWR, 12,980 lbs (5888 kg) capacity
- Rear Axle, Full-floating single-speed, 14,550 lbs. (6600 kg) - capacity with oil lubricated rear wheel bearings
- Rear Axle Ratio, 5.571:1
- Rear Suspension, Steel Alloy Multi-Leaf, 14,550 lbs. (6600 kg) capacity - Semi-elliptical main and auxiliary leaf springs. Includes shock absorbers.
- Rear Wheels, 19.5 x 6.0, 6-hole disc, painted white
- Rear Tires, 225/70R19.5F (12 ply) tubeless Radial, all season tread.
- Wheelbase, 109" (276.9 cm) - includes ladder type channel frame. Full C section straight frame 33.5 inches (85.1 cm) wide. Yield strength 44,000 psi (303,369 kPa) section modulus 7.20 cu.in. and RBM 316,800 lb-ft/in per rail.
- Fuel Tank, Single, 30-gallon (113.6L) rectangular fuel tank - Mounted between frame rail through the rail fuel fill. Tokyo-Roki heated fuel water separator mounted on the frame rail with dash mounted warning light.
- Cab Mounts, All steel low cab forward - BBC 66.8 in. (169.7 cm) 45 deg. mechanical tilt with torsion assist.
- Windows, Tinted glass
- Mirrors, Dual cab mounted exterior
- Paint Scheme, Solid
- Color, Arctic White
- Tilt and telescoping steering column.
- Cruise control
- Two way roof ventilator
- Power windows & door locks
- Seats, Driver, Jacquard flat woven breatheable cloth covered reclining highback - with two single occupant fold down passenger seats
- Floor mats
- Front Frame Rating: - TBD -
- Cold Cranking Amps @ 0° F (Primary): 750
- Cold Cranking Amps @ 0° F (2nd): 750
- Maximum Alternator Capacity (amps): 110
- Maximum Alternator Watts: 1320
- Total Cooling System Capacity (qts): 18.4
- Gross Axle Wt Rating - Front (lbs): 6830
- Gross Axle Wt Rating - Rear (lbs): 12980
- Curb Weight - Front (lbs): 3770
- Curb Weight - Rear (lbs): 2260
- Gross Vehicle Weight Rating Cap (lbs): 17950
- Gross Combined Wt Rating (lbs): 19500
- Suspension Type - Front: Tapered Leaf
- Suspension Type - Rear: Multi-Leaf
- Spring Capacity - Front (lbs): 8440
- Spring Capacity - Rear (lbs): 14550
- Axle Type - Front: Reverse I-Beam
- Axle Type - Rear: Full-Floating
- Axle Capacity - Front (lbs): 6830
- Axle Capacity - Rear (lbs): 14550
- Axle Ratio (:1) - Rear: 5.571
- Shock Absorber Diameter - Front (mm): 45
- Shock Absorber Diameter - Rear (mm): 45
- Stabilizer Bar Diameter - Front (in): 1.65
- Brake Type: Power
- Brake ABS System: Four Wheel
- Disc - Front (Yes or ): Yes
- Front Brake Rotor Diam x Thickness (in): 14.3 x - TBD -
- Drum - Rear (Yes or ): Yes
- Rear Drum Diam x Width (in): 12.6 x 4.72
- Front Tire Order Code: XTN/R3M
- Rear Tire Order Code: YTN/S3M
- Front Tire Size: 225/70R19.5F
- Rear Tire Size: 225/70R19.5F
- Front Tire Capacity (lbs): 3450
- Rear Tire Capacity (lbs): 3245
- Revolutions/Mile @ 45 mph - Front: 643
- Revolutions/Mile @ 45 mph - Rear: 643
- Number Of Tires Front: 2
- Number Of Tires Rear: 4
- Front Wheel Size (in): 19.5 x 6.0
- Rear Wheel Size (in): 19.5 x 6.0
- Front Wheel Offset (mm): 127.0
- Rear Wheel Offset (mm): 127.0
- # of Bolt Holes - Front: 6
- # of Bolt Holes - Rear: 6
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Front Bolt Pattern: 6 Hole JIS 8.75"
- Rear Bolt Pattern: 6 Hole JIS 8.75"
- Steering Type: Power
- Steering Ratio (:1), On Center: 18.8 - 20.9
- Steering Ratio (:1), At Lock: 18.8 - 20.9
- Turning Diameter - Curb to Curb (ft): 33.5
- Turning Diameter - Wall to Wall (ft): 38.1
- Frame Type: Ladder
- Sect Modulus Rails Only (in³): 7.20
- Frame RBM (N/A): 316800
- Frame Strength (lbs): 44000
- Frame Thickness (in): 8.5 X 2.76 X 0.24
- Fuel Tank Capacity, Approx (gal): 30
- Fuel Tank Location: In frame rail
- Wheelbase (in): 109.0
- Length, Overall w/o rear bumper (in): 198.3
- Width, Max w/o mirrors (in): 78.5
- Height, Overall (in): 88.9
- Overhang, Front (in): 46.1
- Overhang, Rear w/o bumper (in): 43.1
- Front Bumper to Back of Cab (in): 66.8
- Cab to Axle (in): 88.4
- Cab to End of Frame (in): 131.5
- Ground to Top of Frame (in): 32.8
- Frame Width, Rear (in): 33.5
- Ground Clearance, Front (in): 8.6
- Ground Clearance, Rear (in): 8.6
- Body Length Default Value (ft): 12
- Passenger Capacity: 3
- Front Head Room (in): 42.5
- Front Leg Room (in): 39.2
- Front Shoulder Room (in): 70.7
- Front Hip Room (in): 66.6
- Vehicle Name: Isuzu W5S042 NQR DSL REG
- Body Style: Tilt Chassis Cab
- Driver Ratio: 1
- Torque @ Clutch Engage (ft-lbs): 265
- Torque Converter: 1.745
- Static Loaded Radius (in): 15.1
- Max Speed For Gradeability: 71
